2023 Beneteau America Flyer 9 Spacedeck

HULL

• Technology: Air Step ® • Patent: Beneteau Composition:
• Sandwich (polyester resin - fiberglass - balsa core)
• White hull
• Winching ring on bow

DECK

Composition:

• Sandwich (polyester resin - fiberglass - balsa core)

MOORING - ANCHORING GEAR

• Stainless steel bow fitting with roller

• Self-bailing mooring locker with hatch cover

• Eye bolt to secure mooring

• 2 Forward cleats + 2 Cleats amidships + 2 Aft cleats in aluminum,
  250 mm / 10’’ SAFETY ON DECK

• Stainless steel forward hand rail
  Elegance version: Black lacquered stainless steel forward hand rail

• 2 Catwalks

• Wide sideways around the consol:
  - portside: 0,37 m / 1’3’’
  - starboard: 0,37 m / 1’3’’

COCKPIT

• Wide and deep self-bailing cockpit (Freeboard: 0,78 m / 2’7’’)

• 3 person cockpit seat with fixed backrest and stainless steel hand
  rail: 1,60 x 0,44 m / 5’3’’ x 1’5’’
  Elegance version: 3 person cockpit seat with black hand rails and backrest that can be converted into a sun deck 1,60 x 0,90 m / 5’3’’ x 2’11’’

• Removeable teak cockpit table with 3 integrated cup holders

• 1 Large lockable central cockpit locker with gas piston assisted opening

• Stowage under the central cockpit seat (BIB location)

• Stowage under the cockpit seat

• Rotomolded fuel tanks (2 x 200 L / 2 x 53 US Gal) at the bottom of the cockpit compartment, in waterproof and ventilated compartment

• 2 Fuel filler on aft freeboards (port and starboard)

• 2 access points to the bathing platform

• 2 safety gates

• Telescopic swimming ladder beneath port side platform, with hand rail

• Cockpit shower

• All-round light on samson post

• Navigation lights (port and starboard)

• Bench seat in front of console with arm rest and 2 hand rails

• Tilting side platform with mechanical mechanism (Length: 1,60 m / 5’3’’ x Height: 0,85 m / 2’9’’)

• 4 Forward cup holders

• 4 Cup holders in cockpit

• 2 Rod holders

• 2 Handrails

STEERING STATION

• Windscreen PMMA light grey tinted
• Handrail around the windscreen
• Center console
• Dashboard with location for electronics , max. 12’’ screen, rpm and trim
• Fuel gauge
• USB socket
• Steering wheel
• Location for top gas throttle (Throttle and instruments delivered with pre-rigging)
• Fitted footrests
• Hydraulic steering
• leaning post / High comfort pilot and copilot bench seat with built-in function Bolster
• Hatch cover under the leaning post
• Co-pilot hand rail
• Cabin access through sliding door in translucent grey PMMA

OUTSIDE KITCHEN

• Sink with 2 bowls
• Teak counter-top
• Space for gas oven (In Comfort trim level)
